PhilipsPHILIPS BRIGHTVIEW FEATURES

  • 59 Photo-multiplier tubes interfaced to 59 A/D Converters
  • Dual NaI, 54 cm x 40.6 cm (21.25" x 16") FOV detectors, 9.5 mm (3/8") thick crystal
  • Enhanced resolution and uniformity detector specifications
  • Energy independent performance up to 300 keV
  • Useful detector energy range: 56 to 662 keV
  • Digital real-time energy, linearity, and uniformity correction
  • Automatic, single button touch for bed imaging, quality control, upright imaging, and other positions.
  • CardioTrac: Automated cardiac setup and with tracking zoom electronics
  • Gantry aperture of 96.5 cm (38 inches) for imaging large patients
  • LCD touch screen camera interface on the gantry
  • Ergonomically designed, wireless (RF) hand controller
  • Caudal-cephalic tilt- +/- 15 degrees perpendicular to the axis of rotation
  • BodyGuard automatic body contouring for SPECT and TB applications
  • Patient table weight limit: 450 lbs.
  • Smart Step: Provides tremendous workflow efficiency
  • Up to 16 energy windows
  • Basic Concurrent Imaging
  • 48.3 cm (19") Flat panel (wall mounted or cart-based)

phillipsadac-forte-new-crop 0PHILIPS/ADAC FORTE FEATURES

  • Two (2) matched detectors for increased throughput and superior image quality
  • Two (2) 3/8” crystals with 20” x 15” large field of view (LFOV) detectors
  • Fifty-five (55) high resolution photomultiplier tubes per detector
  • High performance detector electronics providing excellent resolution
  • Dedicated maintenance and tuning process for stability and reliability
  • Auto gain, energy, linearity, and corrections
  • ColliMATE automated collimator exchanger
  • Full complement of clinical software for nuclear medicine & nuclear cardiology
  • Minimum room dimensions: 13’ x 18’
  • Patient table weight limit: 400 lbs

phillipsadac-forte-new-crop 0PHILIPS/ADAC CARDIOMD FEATURES

  • Fixed 90 degree detectors
  • Two (2) matched detectors for increased throughput and superior image quality
  • Two (2) 3/8” crystals with 14.6” x 8.5” field of view (FOV) detectors
  • Twenty-four (24) high resolution photomultiplier tubes per detector
  • High performance detector electronics providing excellent resolution
  • Auto gain, energy, linearity, and uniformity corrections
  • Preprogrammed gantry motions with digital LED displays
  • Full complement of clinical software for nuclear medicine & nuclear cardiolgoy
  • Compact integrated design to fit into a 10’ x 11’ room (supine/prone long table)
  • Dedicated maintenance and tuning process for stability and reliability
  • Patient table weight limit: 400 lbs
