SIEMENS E.CAM SERIES FEATURES

Available in single, dual, and variable angle detector configurations
3/8” crystals with 21” x 15.25” large field of view (LFOV) detectors
Fifty-nine (59) high-resolution photomultiplier tubes per detector
High-performance detector electronics providing excellent resolution
Dedicated maintenance and tuning process for stability and reliability
Automatic body contouring for whole body and SPECT
Multi-positional LCD flat panel display patient positioning monitor
A full complement of clinical software for nuclear medicine & nuclear cardiology
Fully functional imaging room dimensions: 16.5’ x 19’
Patient table weight limit: 400 lbs

SIEMENS C.CAM FEATURES

Fixed 90 dual detector system
Two (2) 3/8” crystals with 14.6” x 8.4” field of view (FOV) detectors
Twenty-four (24) high-resolution photomultiplier tubes per detector
60 – 170 KeV energy range
LEHR and/or LEAP collimators
Manual collimator exchanger
Pentium III single monitoring acquisition station
A full complement of clinical software for nuclear medicine & nuclear cardiology
Minimum room dimensions: 10’ x 9’
Reclining patient table weight limit: 450 lbs

High-resolution digital detector assembly with 3/8″ NaI crystal
Pass through open gantry design
Caudal tilt allows for precise positioning of static and dynamic acquisitions
Automatic body contouring minimizes detector to patient distance for optimal SPECT imaging resolution
LEHR collimator set
Symbia collimator cart supports storage and exchange of two collimator pairs
Syngo workflow
E.soft workstation
